Overview
These steel roller shutters are made from roll formed interlocking steel slats for additional strength with the ability to replace each slat individually.
Options for manual and motorised operation.
Also available are wind-lock guides for areas exposed to excessive wind conditions.
Fixed, sliding or hinged mullions and wicket gates also available on request.
Available in a range of finishes and colours and custom-made, the slat type door on these roller shutters makes them superior to continuous sheet type doors.
Applications
Metalbilt steel roller shutters are ideal for projects where strength, security, and durability is required including:
- Factories
- Warehouses
- Carparks
- Shop fronts
- Industrial buildings
| STANDARD SPECIFICATIONS |
- Assembled from roll-formed galvanised steel interlocking slats.
- Slats can be replaced individually if damaged.
- Guides are roll-formed galvanised steel, with the choice of standard or wind locked.
- Helically wound torsion springs counterbalance the weight of the curtain.
- Operate manually by spring balance or with motorised system (incorporating automatically engaging hand chain for power failures).
- Wind locks are recommended for openings over 5m wide or where extra security is required.
- Low side room and overhead motorising options available.
- Vented and perforated curtains available.
- Hinged and sliding mullions available.
- Wicket gates available.
|
| SKIN THICKNESS |
- Maximum width – 8 metres
- Maximum height – 7.5 metres
- Maximum opening – 45m2
|
| Finish |
Standard cold rolled galvanised or powder-coating
|
| Warranty Period |
1 Year |
